Scaling an AKS cluster

The easiest way is through the portal where we could easily scale to a 100 nodes using the slider under the scale setting:

horizontal scaling - scaling out and in the number of instances in our cluster

Scaling with the command line is just as easy.

$ az aks show --resource-group idj-aks --name idj-aks --query agentPoolProfiles
[
  {
    "count": 1,
    "maxPods": 110,
    "name": "agentpool",
    "osDiskSizeGb": 30,
    "osType": "Linux",
    "storageProfile": "ManagedDisks",
    "vmSize": "Standard_DS2_v2"
  }
]

$ az aks scale --resource-group idj-aks --name idj-aks --node-count 3
 - Running ..

{
  "aadProfile": null,
  "addonProfiles": {
    "httpApplicationRouting": {
      "config": null,
      "enabled": false
    },
    "omsagent": {
      "config": {
        "logAnalyticsWorkspaceResourceID": "/subscriptions/d955c0ba-ffff-ffff-ffff-fffffffb22d/resourceGroups/DefaultResourceGroup-EUS/providers/Microsoft.OperationalInsights/workspaces/DefaultWorkspace-d955c0ba-ffff-ffff-ffff-ffffffffb22d-EUS"
      },
      "enabled": true
    }
  },
  "agentPoolProfiles": [
    {
      "count": 3,
      "dnsPrefix": null,
      "fqdn": null,
      "maxPods": 110,
      "name": "agentpool",
      "osDiskSizeGb": 30,
      "osType": "Linux",
      "ports": null,
      "storageProfile": "ManagedDisks",
      "vmSize": "Standard_DS2_v2",
      "vnetSubnetId": null
    }
  ],
  "dnsPrefix": "idj-aks-01",
  "enableRbac": false,
  "fqdn": "idj-aks-01-259d9b82.hcp.centralus.azmk8s.io",
  "id": "/subscriptions/d955c0ba-ffff-ffff-ffff-fffffffb22d/resourcegroups/idj-aks/providers/Microsoft.ContainerService/managedClusters/idj-aks",
  "kubernetesVersion": "1.12.6",
  "linuxProfile": null,
  "location": "centralus",
  "name": "idj-aks",
  "networkProfile": {
    "dnsServiceIp": "10.0.0.10",
    "dockerBridgeCidr": "172.17.0.1/16",
    "networkPlugin": "kubenet",
    "networkPolicy": null,
    "podCidr": "10.244.0.0/16",
    "serviceCidr": "10.0.0.0/16"
  },
  "nodeResourceGroup": "MC_idj-aks_idj-aks_centralus",
  "provisioningState": "Succeeded",
  "resourceGroup": "idj-aks",
  "servicePrincipalProfile": {
    "clientId": "eb011c9e-3d44-4e3e-af80-59639911a101",
    "keyVaultSecretRef": null,
    "secret": null
  },
  "tags": null,
  "type": "Microsoft.ContainerService/ManagedClusters"
}

We can query again, but you can see the changes already reflected in the activity log and scale panes in the portal:

Activity log shows scaling activities
The "Scale" section also shows our instance count

This same process can be used to scale down your cluster.  Presently (via comments on the documentation) there appears to be an issue with aks scale (down) immediately terminating nodes and not applying kubectl drain.

$ az aks scale --resource-group idj-aks --name idj-aks --node-count 1

{
  "aadProfile": null,
  "addonProfiles": {
    "httpApplicationRouting": {
      "config": null,
      "enabled": false
    },
    "omsagent": {
      "config": {
        "logAnalyticsWorkspaceResourceID": "/subscriptions/d955c0ba-ffff-ffff-ffff-ffffffffffff/resourceGroups/DefaultResourceGroup-EUS/providers/Microsoft.OperationalInsights/workspaces/DefaultWorkspace-d955c0ba-ffff-ffff-ffff-fffffffb22d-EUS"
      },
      "enabled": true
    }
  },
  "agentPoolProfiles": [
    {
      "count": 1,
      "dnsPrefix": null,
      "fqdn": null,
      "maxPods": 110,
      "name": "agentpool",
      "osDiskSizeGb": 30,
      "osType": "Linux",
      "ports": null,
      "storageProfile": "ManagedDisks",
      "vmSize": "Standard_DS2_v2",
      "vnetSubnetId": null
    }
  ],
  "dnsPrefix": "idj-aks-01",
  "enableRbac": false,
  "fqdn": "idj-aks-01-259d9b82.hcp.centralus.azmk8s.io",
  "id": "/subscriptions/d955c0ba-ffff-ffff-ffff-8fed74cbb22d/resourcegroups/idj-aks/providers/Microsoft.ContainerService/managedClusters/idj-aks",
  "kubernetesVersion": "1.12.6",
  "linuxProfile": null,
  "location": "centralus",
  "name": "idj-aks",
  "networkProfile": {
    "dnsServiceIp": "10.0.0.10",
    "dockerBridgeCidr": "172.17.0.1/16",
    "networkPlugin": "kubenet",
    "networkPolicy": null,
    "podCidr": "10.244.0.0/16",
    "serviceCidr": "10.0.0.0/16"
  },
  "nodeResourceGroup": "MC_idj-aks_idj-aks_centralus",
  "provisioningState": "Succeeded",
  "resourceGroup": "idj-aks",
  "servicePrincipalProfile": {
    "clientId": "eb011c9e-3d44-4e3e-af80-59639911a101",
    "keyVaultSecretRef": null,
    "secret": null
  },
  "tags": null,
  "type": "Microsoft.ContainerService/ManagedClusters"
}

I would argue scaling down should always be immediate and a properly designed system should handle node failures.  It’s worth diving deeper in this but generally a kubernetes deployment will restore pods that are terminated unexpectedly.  For now, assume scale downs could impact users in production loads and plan accordingly.

Auto-Scaling

While manually scaling works fantastic when we wish to plan and know costs, sometimes we wish for a system to scale based on load. In AWS we might apply a scaling set policy to the instances behind an EKS, but Azure recently added a very similar feature (still in preview) - autoscaling AKS clusters.

First we have to enable this feature on our account:

$ az feature register --name VMSSPreview --namespace Microsoft.ContainerService
Once the feature 'VMSSPreview' is registered, invoking 'az provider register -n Microsoft.ContainerService' is required to get the change propagated
{
  "id": "/subscriptions/d955c0ba-ffff-ffff-ffff-fffffffffb22d/providers/Microsoft.Features/providers/Microsoft.ContainerService/features/VMSSPreview",
  "name": "Microsoft.ContainerService/VMSSPreview",
  "properties": {
    "state": "Registering"
  },
  "type": "Microsoft.Features/providers/features"
}

We can then verify it is enabled:

$ az feature list -o table --query "[?contains(name, 'Microsoft.ContainerService/VMSSPreview')].{Name:name,State:properties.state}"
Name                                    State
--------------------------------------  ----------
Microsoft.ContainerService/VMSSPreview  Registered

We can check on the provider for the containerization service.  This will let us know when it’s enabled:

$ az provider register --namespace Microsoft.ContainerService
Registering is still on-going. You can monitor using 'az provider show -n Microsoft.ContainerService'

note: I found that "on-going" message days later while i was actively using the cluster. checking back a week later it was null.  So i would not trust that message when initially setting up your auto-scaling clusters.

There are two ways AKS can scale the cluster using this service:

  1. Cluster autoscaler - using this, AKS will scale up when there are no nodes left for kubernetes to schedule a pod
  2. Horizontal pod autoscaler - this uses the Metrics Server (recall we enabled that on the cluster) to determine scaling needs (out and in) based on resource metrics.

According to Microsoft, they are often run together:

The two autoscalers can work together, and are often both deployed in a cluster. When combined, the horizontal pod autoscaler is focused on running the number of pods required to meet application demand. The cluster autoscaler is focused on running the number of nodes required to support the scheduled pods.

Creating an Auto-Scaling cluster:

Note: only a handful of regions support auto-scaling cluster. The list as of this writing includes eastus2euap, westcentralus, centraluseuap, westus, westeurope, australiaeast, and eastus.  For the demo i'll use eastus, but i saw guides using Canadian regions, so check often.

$ az aks create \
>  --resource-group idj-aks-as1 \
>  --name idj-aks-as1-aks1 \
>  --kubernetes-version 1.12.6 \
>  --node-count 1 \
>  --enable-vmss \
>  --enable-cluster-autoscaler \
>  --min-count 1 \
>  --max-count 3 \
>  --generate-ssh-keys
The behavior of this command has been altered by the following extension: aks-preview
SSH key files '/Users/isaac.johnson/.ssh/id_rsa' and '/Users/isaac.johnson/.ssh/id_rsa.pub' have been generated under ~/.ssh to allow SSH access to the VM. If using machines without permanent storage like Azure Cloud Shell without an attached file share, back up your keys to a safe location
Finished service principal creation[##################################]  100.0000%

QUICK TIP

I found my commands did not exist and assumed i was in the wrong region, however Auto-scaling is a relatively new feature that requires Azure CLI version 2.0.55 or later.  You can check your version with --version:

$ az --version
azure-cli (2.0.42)

Follow this guide (https://docs.microsoft.com/en-us/cli/azure/install-azure-cli?view=azure-cli-latest) to update to the latest. And try to add the preview extension again:

$ az extension add --name aks-preview
The installed extension 'aks-preview' is in preview.

When completed you should see output like this:

When complete, the output should look like this:

$ az aks create \
>  --resource-group idj-aks-as1 \
>  --name idj-aks-as1-aks1 \
>  --kubernetes-version 1.12.6 \
>  --node-count 1 \
>  --enable-vmss \
>  --enable-cluster-autoscaler \
>  --min-count 1 \
>  --max-count 3 \
>  --generate-ssh-keys
The behavior of this command has been altered by the following extension: aks-preview
SSH key files '/Users/isaac.johnson/.ssh/id_rsa' and '/Users/isaac.johnson/.ssh/id_rsa.pub' have been generated under ~/.ssh to allow SSH access to the VM. If using machines without permanent storage like Azure Cloud Shell without an attached file share, back up your keys to a safe location
{
  "aadProfile": null,
  "addonProfiles": null,
  "agentPoolProfiles": [
    {
      "count": 1,
      "enableAutoScaling": true,
      "maxCount": 3,
      "maxPods": 110,
      "minCount": 1,
      "name": "nodepool1",
      "osDiskSizeGb": 30,
      "osType": "Linux",
      "type": "VirtualMachineScaleSets",
      "vmSize": "Standard_DS2_v2",
      "vnetSubnetId": null
    }
  ],
  "apiServerAuthorizedIpRanges": null,
  "dnsPrefix": "idj-aks-as-idj-aks-as1-d955c0",
  "enableRbac": true,
  "fqdn": "idj-aks-as-idj-aks-as1-d955c0-2f330e0d.hcp.eastus.azmk8s.io",
  "id": "/subscriptions/d955c0ba-ffff-ffff-ffff-8fed74cbb22d/resourcegroups/idj-aks-as1/providers/Microsoft.ContainerService/managedClusters/idj-aks-as1-aks1",
  "kubernetesVersion": "1.12.6",
  "linuxProfile": {
    "adminUsername": "azureuser",
    "ssh": {
      "publicKeys": [
        {
          "keyData": "ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAABAQC8kZzEtkFFFFFFFFF0q6h41g5hUwPtOUPjNWPIKm4djmy4+C4+Gtsxxh5jUFooAbwl+DubFZogbU1Q5aLOGKSsD/K4XimTyOhr90DO47naCnaSS0Rg0XyZlvQsHKwcXGuGOleCMhBFFFFFFFFFFFFKQyz0WHWo7YGA6YAgtvzn1C5W0l7cT0AXgOfFEAGF31nqqTuRVBbBmosq1qhXJlVt+PO32MqmxZv44ZuCP1jWjyTz1rbQ1OLHCxP/+eDIlpOlkYop4XgwiHHMRn/rxHFTKOAxtFOccFw9KEnDM0j0M5FRBj5qFFFFFFFFIz"
        }
      ]
    }
  },
  "location": "eastus",
  "name": "idj-aks-as1-aks1",
  "networkProfile": {
    "dnsServiceIp": "10.0.0.10",
    "dockerBridgeCidr": "172.17.0.1/16",
    "networkPlugin": "kubenet",
    "networkPolicy": null,
    "podCidr": "10.244.0.0/16",
    "serviceCidr": "10.0.0.0/16"
  },
  "nodeResourceGroup": "MC_idj-aks-as1_idj-aks-as1-aks1_eastus",
  "provisioningState": "Succeeded",
  "resourceGroup": "idj-aks-as1",
  "servicePrincipalProfile": {
    "clientId": "40ee21ef-fa9d-42e9-8da9-51271b90a154",
    "secret": null
  },
  "tags": null,
  "type": "Microsoft.ContainerService/ManagedClusters"
}

Now that our cluster is created you may wish to look up the autoscaling settings under the kubernetes cluster or even something in our resource group - however neither are there:

Scale settings are disabled
Only one entry in the AKS resource group

Instead you’ll find Azure has created a new resource group to contain the NSG, Route Table, VNet and Virtual machine scale set.

Our VMSS in the nodepool

Checking the Scaling details, we see that by default the scaling policy isnt enabled:

However, it's easy to configure.  Let's start by adding a condition to scale out on CPU.

Adding a scale out policy

Then let's set up helm and try putting some load on our cluster.

First, even though we didn’t explicitly enable RBAC, i found that AKS did on our behalf anyways as is the behaviour on the latest Kubernetes versions and thusly you’ll need to install helm with RBAC enabled.

Following the helm guide:

$ vi helm-rbac.yaml
$ cat helm-rbac.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
  name: tiller
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: tiller
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
  - kind: ServiceAccount
    name: tiller
    namespace: kube-system
$ kubectl apply -f helm-rbac.yaml
serviceaccount/tiller created
clusterrolebinding.rbac.authorization.k8s.io/tiller created
$ helm init --service-account tiller --upgrade
$HELM_HOME has been configured at /Users/isaac.johnson/.helm.

Tiller (the Helm server-side component) has been upgraded to the current version.
Happy Helming!

Then to test, let's set up SonarQube again like we did in our first Part.

$ helm install stable/sonarqube
NAME:   hissing-gorilla
LAST DEPLOYED: Sat Mar 16 22:29:20 2019
NAMESPACE: default
STATUS: DEPLOYED

RESOURCES:
==> v1/ConfigMap
NAME                                       DATA  AGE
hissing-gorilla-sonarqube-config           0     1s
hissing-gorilla-sonarqube-copy-plugins     1     1s
hissing-gorilla-sonarqube-install-plugins  1     1s
hissing-gorilla-sonarqube-tests            1     1s

==> v1/PersistentVolumeClaim
NAME                        STATUS   VOLUME   CAPACITY  ACCESS MODES  STORAGECLASS  AGE
hissing-gorilla-postgresql  Pending  default  1s

==> v1/Pod(related)
NAME                                         READY  STATUS             RESTARTS  AGE
hissing-gorilla-postgresql-799d79995c-67pfp  0/1    Pending            0         0s
hissing-gorilla-sonarqube-5c84c7447f-p7pvf   0/1    ContainerCreating  0         0s

==> v1/Secret
NAME                        TYPE    DATA  AGE
hissing-gorilla-postgresql  Opaque  1     1s

==> v1/Service
NAME                        TYPE          CLUSTER-IP    EXTERNAL-IP  PORT(S)         AGE
hissing-gorilla-postgresql  ClusterIP     10.0.214.153  <none>       5432/TCP        1s
hissing-gorilla-sonarqube   LoadBalancer  10.0.23.136   <pending>    9000:31894/TCP  0s

==> v1beta1/Deployment
NAME                        READY  UP-TO-DATE  AVAILABLE  AGE
hissing-gorilla-postgresql  0/1    1           0          0s
hissing-gorilla-sonarqube   0/1    1           0          0s

NOTES:
1. Get the application URL by running these commands:
     NOTE: It may take a few minutes for the LoadBalancer IP to be available.
           You can watch the status of by running 'kubectl get svc -w hissing-gorilla-sonarqube'
  export SERVICE_IP=$(kubectl get svc --namespace default hissing-gorilla-sonarqube -o jsonpath='{.status.loadBalancer.ingress[0].ip}')
  echo http://$SERVICE_IP:9000

And we can see it running right away:

$ kubectl get pods
NAME                                          READY   STATUS    RESTARTS   AGE
hissing-gorilla-postgresql-799d79995c-67pfp   1/1     Running   0          3m41s
hissing-gorilla-sonarqube-5c84c7447f-p7pvf    0/1     Running   3          3m41s

But without a policy set, we won’t see any scaling occur:

I want to check my cluster status, but RBAC makes that a bit more complicated.  We will need to get a dashboard user created first and use that to log in:

$ vi dashboard-rbac.yaml
$ cat dashboard-rbac.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
  name: aks-dashboard-admin
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: aks-dashboard-admin
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: aks-dashboard-admin
  namespace: kube-system
$ kubectl apply -f dashboard-rbac.yaml
serviceaccount/aks-dashboard-admin created
clusterrolebinding.rbac.authorization.k8s.io/aks-dashboard-admin created
$ kubectl get secret --namespace dashboard-admin -o jsonpath="{.secrets[0].name}") -o jsonpath="{.data.token}" | base64 --decode
eyJhbGciOiJSUxxxxxxxxxxx3JM

You can also do this manually without the yaml:

$ kubectl create serviceaccount kubernetes-dashboard -n kube-system
Error from server (AlreadyExists): serviceaccounts "kubernetes-dashboard" already exists
$ kubectl create clusterrolebinding kubernetes-dashboard -n kube-system --clusterrole=cluster-admin --serviceaccount=kube-system:kubernetes-dashboard
clusterrolebinding.rbac.authorization.k8s.io/kubernetes-dashboard created
$ kubectl get secret $(kubectl get serviceaccount kubernetes-dashboard -n kube-system -o jsonpath="{.secrets[0].name}") -n kube-system -o jsonpath="{.data.token}" | base64 --decode
eyJhb…..

Then we can create a proxy tunnel and browse:

$ az aks browse --resource-group idj-aks-as1 --name idj-aks-as1-aks1

You will see a spew of errors until you login:

http://127.0.0.1:8001/#!/login

Note: While that token above should have worked, ultimately i gave up trying and used the kube-config (cp ~/.kube/config ~/my-kube-config so you can see it).  That worked fine.

In the dashboard we can now see our release (which matched our helm install) and that it really isn't causing much load:

Our first test is to see if we can’t load this one node cluster up and see some performance degradation…

Hammering a Cluster

We can actually scale from inside the dashboard:

From Deployments, choose a deployment and scale it to change the requested number of pods

Let’s scale the Postgres to 10 active pods and see what the cluster does:

scaling to 10 pods brought our CPU up - almost a whole core.

Scaling to 10 pods of each, we hit our memory threshold first:

Our single node cluster hit the max memory before CPU, unable to deploy the 20th pod

However, because we don’t yet have the policy enabled, we are still just using one node:

The one little Node desperately trying to manage the load

Scaling Policy

Let’s set up that scaling policy and see if we can’t help this cluster out.  We will create a scaling set and set up a rule to scale out when CPU (on average) exceeds 25%:

A scale out policy defined in the VMSS scaling section

In a few minutes not only will we scale enough nodes to cover the Deployments, we will see the new size reflected in the dashboard:

This is hard to read, but the point is the memory and CPU graphs going down as we see 3 nodes have been brought up to handle the load.

This worked great, but we ideally would like to scale back in when the demand becomes low otherwise we will only ever grow the cluster.

Let’s add a scale in rule on our scale set:

We can add a scale in rule to the same condition block

Now, just to make sure we trigger the rule, let’s also decrease our deployment pod counts down to 1:

We set our desired to 1 in both cases. AKS will start to actively drain pods

We can immediately see them starting to terminate in the pods list:

$ kubectl get pods
NAME                                          READY   STATUS        RESTARTS   AGE
hissing-gorilla-postgresql-799d79995c-67pfp   0/1     Terminating   1          67m
hissing-gorilla-postgresql-799d79995c-72r7b   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-7ksp2   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-7xnsx   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-8dnbm   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-bk77p   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-dhkw5   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-ghps2   1/1     Running       1          33m
hissing-gorilla-postgresql-799d79995c-vntfp   0/1     Terminating   1          33m
hissing-gorilla-postgresql-799d79995c-xvkhs   0/1     Terminating   1          33m
hissing-gorilla-sonarqube-5c84c7447f-22q69    0/1     Evicted       0          30m
hissing-gorilla-sonarqube-5c84c7447f-2bn9j    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-2mlmf    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-2ttwr    0/1     Evicted       0          14m
hissing-gorilla-sonarqube-5c84c7447f-2vmtn    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-2zjhc    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-4p5fr    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-4s8lw    0/1     Terminating   3          19m
hissing-gorilla-sonarqube-5c84c7447f-6flgx    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-6kd4b    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-6kgl7    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-6mrmb    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-6ptf2    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-75djm    1/1     Terminating   1          12m
hissing-gorilla-sonarqube-5c84c7447f-7bxrj    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-7rcw5    0/1     Terminating   2          30m
hissing-gorilla-sonarqube-5c84c7447f-9t4bn    1/1     Running       0          14m
hissing-gorilla-sonarqube-5c84c7447f-9xkjz    1/1     Terminating   0          10m
hissing-gorilla-sonarqube-5c84c7447f-bbvcz    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-bcqb5    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-bpgxv    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-dgg86    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-dl2dc    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-dz5wq    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-dzc9r    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-dzgmm    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-f5pl8    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-f8z4x    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-fhg6r    0/1     Evicted       0          30m
hissing-gorilla-sonarqube-5c84c7447f-gznls    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-hjj67    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-jjrrv    0/1     Evicted       0          30m
hissing-gorilla-sonarqube-5c84c7447f-jp6rh    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-jpdxp    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-k2wt4    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-k7vtq    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-kpt8q    1/1     Terminating   0          12m
hissing-gorilla-sonarqube-5c84c7447f-l5h5b    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-lb6t8    0/1     Evicted       0          12m
hissing-gorilla-sonarqube-5c84c7447f-lfsgl    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-ms2zd    0/1     Evicted       0          30m
hissing-gorilla-sonarqube-5c84c7447f-n25rs    0/1     Evicted       0          29m
hissing-gorilla-sonarqube-5c84c7447f-n54dq    0/1     Evicted       0          12m

Within a few minutes we will start to see the VMSS start to delete unnecessary nodes:

The VMSS reacting to the scale-in policy and deleting unnecessary node instances

In a few moments, we’ll see that reflected in the dashboard as well:

You can see a bit of a spike on the CPU graph just past 23:36 as AKS reacts to a terminated cluster node
as we are only running 2 pods, AKS scales back to the minimum we set (one node)

Vertical Scaling:

First, lets create a fresh scaling cluster:

$ az group create --location eastus --name idj-aks-as2
{
  "id": "/subscriptions/d955c0ba-ffff-ffff-ffff-ffffffffb22d/resourceGroups/idj-aks-as2",
  "location": "eastus",
  "managedBy": null,
  "name": "idj-aks-as2",
  "properties": {
    "provisioningState": "Succeeded"
  },
  "tags": null,
  "type": null
}

$ az aks create --resource-group idj-aks-as2 --name idj-aks-as2-aks1 --kubernetes-version 1.12.6 --node-count 1 --enable-vmss --enable-cluster-autoscaler --min-count 1 --max-count 3 --generate-ssh-keys
The behavior of this command has been altered by the following extension: aks-preview
 - Running ..
{
  "aadProfile": null,
  "addonProfiles": null,
  "agentPoolProfiles": [
    {
      "count": 1,
      "enableAutoScaling": true,
      "maxCount": 3,
      "maxPods": 110,
      "minCount": 1,
      "name": "nodepool1",
      "osDiskSizeGb": 30,
      "osType": "Linux",
      "type": "VirtualMachineScaleSets",
      "vmSize": "Standard_DS2_v2",
      "vnetSubnetId": null
    }
  ],
  "apiServerAuthorizedIpRanges": null,
  "dnsPrefix": "idj-aks-as-idj-aks-as2-d955c0",
  "enableRbac": true,
  "fqdn": "idj-aks-as-idj-aks-as2-d955c0-8cde2d57.hcp.eastus.azmk8s.io",
  "id": "/subscriptions/d955c0ba-ffff-ffff-ffff-fffffffb22d/resourcegroups/idj-aks-as2/providers/Microsoft.ContainerService/managedClusters/idj-aks-as2-aks1",
  "kubernetesVersion": "1.12.6",
  "linuxProfile": {
    "adminUsername": "azureuser",
    "ssh": {
      "publicKeys": [
        {
          "keyData": "ssh-rsa AAAAB3NzaC1yc2EAAAAFFFFFFFFFFFFFFIE1jcQ0q6h41g5hUwPtOUPjNWPIKm4djmy4+C4+Gtsxxh5jUFFFFFFFFFFFFFFK4XimTyOhr90DO47naCnaSS0Rg0XyZlvQsHKwcXGuGOleCMhB2gQ70QAK4X/N1dvGfqCDdKBbTORKQyz0WHWo7YGA6YAgtvzn1C5W0l7cT0AXgOfFEAGF31nqqTuRVBbBmosq1qhXJlVt+PO32MqmxZv44ZuCP1jWjyTz1rbQ1OLHCxP/+eDIlpOlkYop4XgwiHHMRn/rxHFTKOAxtFFFFFFFF/6jhnu7LIz"
        }
      ]
    }
  },
  "location": "eastus",
  "name": "idj-aks-as2-aks1",
  "networkProfile": {
    "dnsServiceIp": "10.0.0.10",
    "dockerBridgeCidr": "172.17.0.1/16",
    "networkPlugin": "kubenet",
    "networkPolicy": null,
    "podCidr": "10.244.0.0/16",
    "serviceCidr": "10.0.0.0/16"
  },
  "nodeResourceGroup": "MC_idj-aks-as2_idj-aks-as2-aks1_eastus",
  "provisioningState": "Succeeded",
  "resourceGroup": "idj-aks-as2",
  "servicePrincipalProfile": {
    "clientId": "40ee21ef-fa9d-42e9-8da9-51271b90a154",
    "secret": null
  },
  "tags": null,
  "type": "Microsoft.ContainerService/ManagedClusters"
}

You'll note the vmSize in the output above:

 "vmSize": "Standard_DS2_v2",

We can look up the instance under the VMSS and see the same reflected in the one instance count:

But perhaps we want to scale up or down (make it bigger or smaller).

Use the Size section to change VMSS machine class

Choosing resize and saving won’t affect our running instance which is still “Standard_DS2_v2”

However, if we go to scaling and scale out:

We will see it scale out and indicate our former is now out of date to the scale set (because of size):

QUICK TIP:

We may get an error telling us that isn't a valid size (i found i could just move to the larger instance in my case):

Failed to update autoscale configuration for 'aks-nodepool1-36739375-vmss'.{
  "error": {
    "details": [],
    "code": "VMSizeIsNotPermittedToEnableAcceleratedNetworkingForVmss",
    "message": "Virtual Machine size Standard_B2s is not in the allowed list of VM sizes for accelerated networking to be enabled on the VM at index 0 for VM Scale Set /subscriptions/d955c0ba-13dc-44cf-a29a-8fed74cbb22d/resourceGroups/MC_idj-aks-as2_idj-aks-as2-aks1_eastus/providers/Microsoft.Compute/virtualMachineScaleSets/aks-nodepool1-36739375-vmss. Allowed sizes: Standard_D3_v2, Standard_D12_v2, Standard_D3_v2_Promo, Standard_D12_v2_Promo, Standard_DS3_v2, Standard_DS12_v2, Standard_DS13-4_v2, Standard_DS14-4_v2, Standard_DS3_v2_Promo, Standard_DS12_v2_Promo, Standard_DS13-4_v2_Promo, Standard_DS14-4_v2_Promo, Standard_F4, Standard_F4s, Standard_D8_v3, Standard_D8s_v3, Standard_D32-8s_v3, Standard_E8_v3, Standard_E8s_v3, Standard_D3_v2_ABC, Standard_D12_v2_ABC, Standard_F4_ABC, Standard_F8s_v2, Standard_D4_v2, Standard_D13_v2, Standard_D4_v2_Promo, Standard_D13_v2_Promo, Standard_DS4_v2, Standard_DS13_v2, Standard_DS14-8_v2, Standard_DS4_v2_Promo, Standard_DS13_v2_Promo, Standard_DS14-8_v2_Promo, Standard_F8, Standard_F8s, Standard_M64-16ms, Standard_D16_v3, Standard_D16s_v3, Standard_D32-16s_v3, Standard_D64-16s_v3, Standard_E16_v3, Standard_E16s_v3, Standard_E32-16s_v3, Standard_D4_v2_ABC, Standard_D13_v2_ABC, Standard_F8_ABC, Standard_F16s_v2, Standard_D5_v2, Standard_D14_v2, Standard_D5_v2_Promo, Standard_D14_v2_Promo, Standard_DS5_v2, Standard_DS14_v2, Standard_DS5_v2_Promo, Standard_DS14_v2_Promo, Standard_F16, Standard_F16s, Standard_M64-32ms, Standard_M128-32ms, Standard_D32_v3, Standard_D32s_v3, Standard_D64-32s_v3, Standard_E32_v3, Standard_E32s_v3, Standard_E32-8s_v3, Standard_E32-16_v3, Standard_D5_v2_ABC, Standard_D14_v2_ABC, Standard_F16_ABC, Standard_F32s_v2, Standard_D15_v2, Standard_D15_v2_Promo, Standard_D15_v2_Nested, Standard_DS15_v2, Standard_DS15_v2_Promo, Standard_DS15_v2_Nested, Standard_D40_v3, Standard_D40s_v3, Standard_D15_v2_ABC, Standard_M64ms, Standard_M64s, Standard_M128-64ms, Standard_D64_v3, Standard_D64s_v3, Standard_E64_v3, Standard_E64s_v3, Standard_E64-16s_v3, Standard_E64-32s_v3, Standard_F64s_v2, Standard_F72s_v2, Standard_M128s, Standard_M128ms, Standard_L8s_v2, Standard_L16s_v2, Standard_L32s_v2, Standard_L64s_v2, SQLGL, SQLGLCore, Standard_D4_v3, Standard_D4s_v3, Standard_D2_v2, Standard_DS2_v2, Standard_E4_v3, Standard_E4s_v3, Standard_F2, Standard_F2s, Standard_F4s_v2, Standard_D11_v2, Standard_DS11_v2, AZAP_Performance_ComputeV17C, AZAP_Performance_ComputeV17C_DDA, Standard_PB6s, Standard_PB12s, Standard_PB24s, Standard_L80s_v2, Standard_M8ms, Standard_M8-4ms, Standard_M8-2ms, Standard_M16ms, Standard_M16-8ms, Standard_M16-4ms, Standard_M32ms, Standard_M32-8ms, Standard_M32-16ms, Standard_M32ls, Standard_M32ts, Standard_M64ls, Standard_E64i_v3, Standard_E64is_v3, Standard_E4-2s_v3, Standard_E8-4s_v3, Standard_E8-2s_v3, Standard_E16-4s_v3, Standard_E16-8s_v3, Standard_E20s_v3, Standard_E20_v3, Standard_D11_v2_Promo, Standard_D2_v2_Promo, Standard_DS11_v2_Promo, Standard_DS2_v2_Promo, Standard_M208ms_v2, Standard_MDB16s, Standard_MDB32s, Experimental_E64-40s_v3, Standard_DS11-1_v2, Standard_DS12-1_v2, Standard_DS12-2_v2, Standard_DS13-2_v2, MSODSG5, Special_CCX_DS13_v2, Special_CCX_DS14_v2."
  }
}

Once the new instance has been created, we deallocate the former instance:

Choose Deallocate from the menu
Clicking yes will stop it without deleting it

Then delete it before changing the instance count.

Note - if we reduce our instances to 1 before deleting it, the VMSS will actually delete the currently running larger instance and break our cluster:

one stopped, one deleting, our cluster is left in a bad state

We can check the VMSS details and see we are now using the larger instance class:

Note the size is now Standard_DS3_v2

Cleaning up:

While you could go nuclear and just start finding and destroying resources, we can do it a bit more elegantly and efficiently.

First, delete the autoscaler from the cluster:

$ az aks update --resource-group idj-aks-as1 --name idj-aks-as1-aks1 --disable-cluster-autoscaler
 - Running ..
$ az aks update --resource-group idj-aks-as1 --name idj-aks-as1-aks1 --disable-cluster-autoscaler
{
  "aadProfile": null,
  "addonProfiles": null,
  "agentPoolProfiles": [
    {
      "count": 1,
      "enableAutoScaling": false,
      "maxCount": null,
      "maxPods": 110,
      "minCount": null,
      "name": "nodepool1",
      "osDiskSizeGb": 30,
      "osType": "Linux",
      "type": "VirtualMachineScaleSets",
      "vmSize": "Standard_DS2_v2",
      "vnetSubnetId": null
    }
  ],
  "apiServerAuthorizedIpRanges": null,
  "dnsPrefix": "idj-aks-as-idj-aks-as1-d955c0",
  "enableRbac": true,
  "fqdn": "idj-aks-as-idj-aks-as1-d955c0-2f330e0d.hcp.eastus.azmk8s.io",
  "id": "/subscriptions/d955c0ba-13dc-44cf-a29a-8fed74cbb22d/resourcegroups/idj-aks-as1/providers/Microsoft.ContainerService/managedClusters/idj-aks-as1-aks1",
  "kubernetesVersion": "1.12.6",
  "linuxProfile": {
    "adminUsername": "azureuser",
    "ssh": {
      "publicKeys": [
        {
          "keyData": "ssh-rsa AAAAB3NzaC1yc2EAAAFFFFFFFFJIE1jcQ0q6h41g5hUwPtOUPjNWPIKm4djmy4+C4+Gtsxxh5jUFooAbwl+DubFZogbU1Q5aLOGFFFFFFFFFFFS0Rg0XyZlvQsHKwcXGuGOleCMhB2gQ70QAK4X/N1dvGfqCDdKBbTORKQyz0WHWo7YGA6YAgtvzn1C5W0l7cT0AXgOfFEAGF31nqqTuRVBbBmosq1qhXJlVt+PO32MqmxZv44FFFFFFFFFFFFP/+eDIlpOlkYop4XgwiHHMRn/rxHFTKOAxtFOccFw9KEnDM0j0M5FRBj5qU1BCa/6jhnu7LIz"
        }
      ]
    }
  },
  "location": "eastus",
  "name": "idj-aks-as1-aks1",
  "networkProfile": {
    "dnsServiceIp": "10.0.0.10",
    "dockerBridgeCidr": "172.17.0.1/16",
    "networkPlugin": "kubenet",
    "networkPolicy": null,
    "podCidr": "10.244.0.0/16",
    "serviceCidr": "10.0.0.0/16"
  },
  "nodeResourceGroup": "MC_idj-aks-as1_idj-aks-as1-aks1_eastus",
  "provisioningState": "Succeeded",
  "resourceGroup": "idj-aks-as1",
  "servicePrincipalProfile": {
    "clientId": "40ee21ef-ffff-ffff-ffff-fffffffa154",
    "secret": null
  },
  "tags": null,
  "type": "Microsoft.ContainerService/ManagedClusters"
}

From there we can see the Resource group (MC_idj-aks-as1_idj-aks-as1-aks1_eastus) we need to remove now that it’s been disconnected from the cluster.

You can then go and cleanup your remaining resources.

The importance of cleanup.

Most services don’t cost that much, but a k8s cluster can really add up fast.  For instance, For 6 days since i wrote the last blog entry, i left up a cluster with autoscaling to validate costs wouldn’t be that high.  It just had one node after all.

But I had neglected to check the VMSS behind the autoscaler which was set, by default, to have one node up.  These are not the tiny little t2.micro/A0 instances.. The are fat little D2 v2 and what’s more DS2 v2.  Decent CPU and SSD storage.  In 6 days, a cluster effectively sitting idle totally nearly US$20.

My $20 vacation oops

It’s for that reason that cleaning up should be something you do (unless you want to explain to the boss the large Microsoft cloud bill on the next CC statement).

Summary:

In this guide we dove head-first into Auto-Scaling AKS clusters.  We explored how to create them, log into the dashboard, and adjust the VM Scaling Set policies to meet our needs.  We tested scaling out and in using a SonarQube helm chart, a practical application of vertical scaling and lastly we cleaned up our resources.
